A professional paper machine making facotry in China

1.High-efficiency power system, equipped with embedded control board and common DC bus energy-saving system, imported MAXI sliting knife group + Taiwan JlAYAN curved paper roll mechanism, servo drive system + 1200 m/min dynamic balance roller, high speed and stability.
2.inteligent rewinding system, plate-type one-piece machine head with arc-shaped rubber roller loosening device, air shaft +precision pressure regulating valve dual control rewinding pressure, pressure self-adjustment technology to ensure the consistency of the tightness of the jumbo roll inside and outside.
3.Automated production module, infrared paper breaking and automatic stop of the whole machine + full-process automatic fast roll changing system, integrated paper cutting/air blowing/tube dropping unmanned operation unit.
4.Strengthened structural design, hydraulic lifting and paper dropping device (load-bearing + 80%), precise and reliable control. 200mm steel plate frame + air spring calendering system.cast iron roller surface self-cleaning + 11kW powerful suction fan
5.Special adaptabilitly, pneumatic soft belt paper feeding system (compatible with 3 tons/$2m jumbo rolls) chrome steel cutter + oil cloth lubrication to extend the life of the knife group.
6,.Safe and convenient control system, CE standard quardrall + emergency stop linkage system,7'touch screen + early warning prompt + partition motor control is safer, paper feeder fine-tuning function + modular tension adjustment design.

Note:can cut women npakin Meltblown nonwoven fabric
